Elephant Grippa Geared Type Trolley - ATS-BCG Series
SKU: ATS-BCG2
$1,256.00
View Details
Order Sheet
| SKU | WLL | Price | Qty | |
|---|---|---|---|---|
| ATS-BCG2 | 2 t | $1,256.00 |
|
|
| ATS-BCG3 | 3 t | $1,581.00 |
|
|
| ATS-BCG5 | 5 t | $2,440.00 |
|
|
| ATS-BCG-10 | 10 t | $5,152.00 |
|
|
| ATS-BCG-20 | 20 t | $11,542.00 |
|
ATS-BCG2
$1,256.00
ATS-BCG3
$1,581.00
ATS-BCG5
$2,440.00
ATS-BCG-10
$5,152.00
ATS-BCG-20
$11,542.00
Capacity Range2–20 T
Beam Range4.4"–8.3"
Drive TypeGEARED
ELEPHANT LIFTING — GRIPPA GEARED TYPE TROLLEY · ATS-BCG SERIES · 2 T – 20 T · SOUTH AFRICA
The Elephant Grippa Geared Type Trolley (ATS-BCG Series) is a heavy-duty GRIPPA geared trolley. Hand-chain geared drive delivers controlled positioning on I-beams with a robust machined frame built for heavy industrial use.
- Heavy-duty GRIPPA series — geared drive
- Controlled load positioning via 10' hand chain
- Capacity range: 2 t – 20 t
- Anti-drop retention on beam
- Made in South Africa
SeriesATS-BCG SERIES
TypeMANUAL TROLLEY
Capacity Range2 T — 20 T
ShippingLTL ON LARGER MODELS
Country of OriginSOUTH AFRICA
HS Code8431.10.0090
Model Lineup — 5 Variants
| Part Number | WLL | Beam Flange | Ship Weight | LTL |
|---|---|---|---|---|
| ATS-BCG2 | 2 T | — | 60 LB | — |
| ATS-BCG3 | 3 T | — | 85 LB | — |
| ATS-BCG5 | 5 T | 4.4" – 8.3" | 161 LB | LTL |
| ATS-BCG-10 | 10 T | — | 295 LB | LTL |
| ATS-BCG-20 | 20 T | — | 760 LB | LTL |
⚠
Verify beam flange width and thickness are within the trolley's rated range before loading. Never exceed the rated WLL. Inspect side plates, axles, wheels, and anti-drop plates before every use. Ensure beam ends have proper stops to prevent roll-off. Remove from service if wheels are worn, axles show deformation, or anti-drop hardware is damaged. Larger capacities ship LTL freight — confirm delivery address accepts LTL before ordering.
ASME B30.11 · HS 8431.10.0090Elephant LiftingManual Trolley — Grippa Geared Type Trolley
