Order Sheet
| SKU | WLL | Price | Qty | |
|---|---|---|---|---|
| APT-0100 | 1 t | $661.00 |
|
|
| APT-0200 | 2 t | $889.00 |
|
|
| APT-0300 | 3 t | $1,096.00 |
|
|
| APT-0600 | 6 t | $1,643.00 |
|
|
| APT-1000 | 10 t | $3,607.00 |
|
APT-0100
$661.00
APT-0200
$889.00
APT-0300
$1,096.00
APT-0600
$1,643.00
APT-1000
$3,607.00
Capacity Range1–10 T
Beam Range2.95"–12.0"
Drive TypePUSH
TIGER LIFTING — ADJUSTABLE PUSH TROLLEY · APT SERIES · 1 T – 10 T · TAIWAN
The Tiger Adjustable Push Trolley (APT Series) is a quick-adjust push trolley. Tool-free width adjustment for fast deployment across varying I-beam flange widths, with push-type operation for manual positioning.
- Quick-adjust — tool-free beam width adjustment
- Push-type operation — manual positioning
- Capacity range: 1 t – 10 t
- Wide beam flange compatibility
- Made in Taiwan
SeriesAPT SERIES
TypeMANUAL TROLLEY
Capacity Range1 T — 10 T
ShippingLTL ON LARGER MODELS
Country of OriginTAIWAN
HS Code8431.10.0090
Model Lineup — 5 Variants
| Part Number | WLL | Beam Flange | Ship Weight | LTL |
|---|---|---|---|---|
| APT-0100 | 1 T | 2.95" – 8.26" | 25 LB | — |
| APT-0200 | 2 T | 2.95" – 8.26" | 32 LB | — |
| APT-0300 | 3 T | 2.95" – 8.26" | 54 LB | — |
| APT-0600 | 6 T | 4.13" – 12.00" | 84 LB | — |
| APT-1000 | 10 T | 6.30" – 12.00" | 320 LB | LTL |
⚠
Verify beam flange width and thickness are within the trolley's rated range before loading. Never exceed the rated WLL. Inspect side plates, axles, wheels, and anti-drop plates before every use. Ensure beam ends have proper stops to prevent roll-off. Remove from service if wheels are worn, axles show deformation, or anti-drop hardware is damaged. Larger capacities ship LTL freight — confirm delivery address accepts LTL before ordering.
ASME B30.11 · HS 8431.10.0090Tiger LiftingManual Trolley — Adjustable Push Trolley
No documents available for this product.
Reviews coming soon.
