Order Sheet
| SKU | WLL | Price | Qty | |
|---|---|---|---|---|
| TPS-0050 | 0.5 t | $278.00 |
|
|
| TPS-0100 | 1 t | $340.00 |
|
|
| TPS-0200 | 2 t | $481.00 |
|
|
| TPS-0300 | 3 t | $670.00 |
|
|
| TPS-0500 | 5 t | $1,140.00 |
|
TPS-0050
$278.00
TPS-0100
$340.00
TPS-0200
$481.00
TPS-0300
$670.00
TPS-0500
$1,140.00
Capacity Range0.5–5 T
Beam Range2.44"–7.63"
Drive TypePUSH
TIGER LIFTING — PUSH TROLLEY · TPS SERIES · 0.5 T – 5 T · TAIWAN
The Tiger Push Trolley (TPS Series) is a push-type trolley for light-duty load positioning by hand. Anti-drop plates retain the trolley on the beam.
- Push-type — manual load positioning
- Anti-drop plates retain on beam
- Capacity range: 0.5 t – 5 t
- Fits standard I-beam flanges
- Made in Taiwan
SeriesTPS SERIES
TypeMANUAL TROLLEY
Capacity Range0.5 T — 5 T
Country of OriginTAIWAN
HS Code8431.10.0090
Model Lineup — 5 Variants
| Part Number | WLL | Beam Flange | Ship Weight | LTL |
|---|---|---|---|---|
| TPS-0050 | 0.5 T | 2.44" – 5.03" | 12 LB | — |
| TPS-0100 | 1 T | 2.44" – 5.03" | 17 LB | — |
| TPS-0200 | 2 T | 3.46" – 6.06" | 28 LB | — |
| TPS-0300 | 3 T | 3.46" – 6.06" | 44 LB | — |
| TPS-0500 | 5 T | 4.17" – 7.63" | 71 LB | — |
⚠
Verify beam flange width and thickness are within the trolley's rated range before loading. Never exceed the rated WLL. Inspect side plates, axles, wheels, and anti-drop plates before every use. Ensure beam ends have proper stops to prevent roll-off. Remove from service if wheels are worn, axles show deformation, or anti-drop hardware is damaged.
ASME B30.11 · HS 8431.10.0090Tiger LiftingManual Trolley — Push Trolley
No documents available for this product.
Reviews coming soon.
