Green Pin S Snatch Block for 2-3/4"–3" Wire Rope – 275,570 lb (125 tonnes) WLL – BKOFFSS35125, 2-3/4"–3"
SKU BKOFFSS35125
$28,314.86
Returns need our approval first. Return policy
Image may not match exactly. Refer to the specs.
SKU BKOFFSS35125
$28,314.86
Returns need our approval first. Return policy
Your cart
Your cart is empty.
Browse products275,570lb
Working load limit, on the headfitting125 tonnes
A snatch block with a Green Pin shackle at the top, for turning a wire rope line or doubling a pull. It takes 2-3/4"–3" rope; the sheave is 37-13/32" outside diameter. The side plate opens, so the rope goes in mid-line.
Carbon steel on conical roller bearings, painted. The rating is marked on the headfitting and is the load there, which is more than the line pull once rope turns through the block: close to twice with the two parts parallel.
